| 基本信息 | |||
| 公告型号 | LMX5181TQZSX6 | ||
| 车身长度 | 10550,10400,10195,10045,10030,9880,9865,9715,9700,9550,9205,9055,9040,8890,8875,8725,8380,8230,7965,7815mm | ||
| 车身宽度 | 2550,2500mm | ||
| 车身高度 | 2950,2860mm | ||
| 整备质量 | 13300kg | ||
| 总质量 | 18000kg | ||
| 最高车速 | 89km/h | ||
| 底盘参数/配置 | |||
| 底盘型号 | SX1180GP6501 | ||
| 前悬后悬 | 1450/3500,1300/3500,1450/3445,1300/3445,1450/3380,1300/3380,1450/3315,1300/3315,1450/3250,1300/3250,1450/3055,1300/3055,1450/2990,1300/2990,1450/2925,1300/2925,1450/2730,1300/2730,1450/2565,1300/2565mm | ||
| 接近离去角 | 23/8,20/8,23/9,20/9,23/10,20/10,23/11,20/11° | ||
| 备注 | |||
| 该车主要用于道路故障车辆,城市违章车辆拖运,主要装置为平板机构,托臂,绞盘等;整车整备质量(kg)/托举质量(kg)(驾驶室准乘人数)对应关系为:13300/4570(2人)/4505(3人);12700/5170(2人)/5105(3人);12200/5670(2人)/5605(3人);11650/6220(2人)/6155(3人);11200/6670(2人)/6605(3人);侧防护材料为Q235,连接方式为螺栓连接;后防护由专用装置代替,离地高为480mm;车长(mm)/前悬(mm)/轴距(mm)/后悬(mm)对应关系:10550/1450/5600/3500,10400/1300/5600/3500,10195/1450/5300/3445,10045/1300/5300/3445,10030/1450/5200/3380,9880/1300/5200/3380,9865/1450/5100/3315,9715/1300/5100/3315,9700/1450/5000/3250,9550/1300/5000/3250,9205/1450/4700/3055,9055/1300/4700/3055,9040/1450/4600/2990,8890/1300/4600/2990,8875/1450/4500/2925,8725/1300/4500/2925,8380/1450/4200/2730,8230/1300/4200/2730,7965/1450/3950/2565,7815/1300/3950/2565;ABS系统生产厂家:西安正昌电子股份有限公司,型号:ZQFB-V;随底盘选装限速装置,限速89km/h;仅采用底盘275/80R22.5,10.00R20 18PR,275/80R22.5 18PR,295/80R22.5 18PR轮胎。 | |||
